ENS ED8004H5-B 4CH TVI/AHD/CVI 5MP DVR

SKU : ED8004H5-B Category

4 Channel Digital Video Recorder(DVR), Maximum. 6Channel (Up to 4Channel BNC/6Channel IP),5 megapixel Lite@10FPS,4MP Lite@15FPS, HDMI/VGA/CVBS(or Spot), Audio,1SATA

Request Quote

ENS ED8004H5-B 4CH TVI/AHD/CVI 5MP DVR



Features:

  • 4CH TVI / AHD video input, support 5MP / 4MP / 3MP / 1080P / 720P / WD1 recording
  • 4CH CVI video input, support 4MP / 3MP / 1080P / 720P / WD1 recording
  • 4CH DVR support 2 CH IPC 5MP / 4MP / 3MP / 1080P / 960P / 720P recording
  • Adopt standard H.265 high profile compression format to get high-quality video at much lower bit rate
  • Intuitive and user-friendly Graphics User Interface ( GUI ), window style operation by mouse
  • Multi-mode recording: manual / timer / motion
  • Playback : 4CH simultaneously playback
  • Search: time slice, time, event ( manual, motion ), tag search
  • Express and flexible backup via USB, network and so on
  • Pentaplex: preview, record, playback, backup and remote access
  • DHCP, DDNS, PPPoE network protocol, IE browse and CMS supported
  • Remote control via IE or CMS : preview, playback, backup, PTZ and configuration
  • Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
  • Multi-user online simultaneously
  • Authorization management, log review and device status review
  • Support 1080P output, true high resolution display
  • Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
  • Support NAT function and QRCode scanning by mobile phone and PAD
  • Powerful smart phone & Pad surveillance with iOS and Andriod OS
  • This professional surveillance Digital Video Recorder works with: Titanium HD Cameras
Brand

Technology

Warranty

Storage

1 SATA HDD x Up to 6 TB capacity

Resolution

Recording Rate

10fps@5MP Lite, 15fps@4MP Lite

Channel

4 CH

Bandwidth In/out

36Mbps / 40Mbps
