ENS ED8416TCPR 5MP 16CH 5-IN-1 Hybrid Digital Video Recorder (DVR) Up To 20 IPC

SKU : ED8416TCPR Category

16 Channel DVR TVI/AHD/CVI/960H/IP H.264 1.5U Case Record, Android, Iphone Remote View | ED8416TCPR. 5MP for HD-TVI / AHD format, 2MP for CVI, 4MP for IP Camera input. Max 4 x 4MP IP Camera.

ENS ED8416TCPR 5MP 16CH 5-IN-1 Hybrid Digital Video Recorder (DVR) Up To 20 IPC



Features:

  • 16 CH TVI / AHD 2.0 video input, 16 CH 1080P / 1080P lite / 720P 16 CH TVI / CVI / AHD video input
  • 16 CH 5MP / 4MP / 4MP lite / 3MP / 1080P / 720P / WD1 recording
  • 4 CH IPC 4MP / 3MP / 1080P / 960P / 720P recording (Up To 20 IPC)
  • Adopt standard H.264 high profile compression format to get high-quality video at much lower bit rate
  • Intuitive and user-friendly Graphics User Interface ( GUI ), window style operation by mouse
  • Multi-mode recording: manual / timer / motion / sensor
  • Playback : 16 CH simultaneously playback
  • Search: time slice, time, event ( manual, sensor, motion ), tag search
  • Express and flexible backup via USB, network and so on
  • Pentaplex: preview, record, playback, backup and remote access
  • DHCP, DDNS, PPPoE network protocol, IE browse and CMS supported
  • Remote control via IE or CMS : preview, playback, backup, PTZ and configuration
  • Dual stream technology for local storage with high definition, remote network transmission and remote surveillance with mobile device
  • Multi-user online simultaneously
  • Authorization management, log review and device status review
  • HDMI 1080P output, true high resolution display
  • Support PTZ preset and auto cruise, up to 255 presets and 8 cruises
  • Support NAT function and QRCode scanning by mobile phone and PAD
  • Powerful smart phone & Pad surveillance with iOS and Andriod OS
Dimensions 43.94 × 39.12 × 7.11 cm
Brand

Technology

Warranty

Storage

4 SATA HDD x Up to 8 TB capacity each

Resolution

Recording Rate

10fps@5MP

Channel

16 CH

Bandwidth In/out

32Mbps / 192Mbps

Reviews

There are no reviews yet.

Be the first to review “ENS ED8416TCPR 5MP 16CH 5-IN-1 Hybrid Digital Video Recorder (DVR) Up To 20 IPC”

Your email address will not be published. Required fields are marked *

ED8416TCPR Specification Sheet

Download

ED8416TCPR Quick Guide

Download

ED8416TCPR Mobile User Manual

Download

ED8416TCPR User Manual

Download
