ENS NKB1000 Network PTZ Controller, Support HD-CVI & IP
Features:
- NV Series IP PTZs
- NV Series NVRs
- NV Series Super NVRs
- Connection: RS485, RS422, USB, RS232 & Network
- Three Dimensional Joystick Control of PTZ Functions
- Preset Position, Auto Scan, Auto Pan, Auto Tour & Pattern Control
- Auxiliary Functions
- On-Screen Menu & User Operation Procedure Tips
- Connect to Smart PSS via USB
- Keyboard Panel Electromagnetically
- Joystick 3-axis, vector-solving, with twisting, return to-center head
- Keyboard Connector RJ-45,RS232,RS485,RS422,USB,
- Keyboard Communication Direct Mode, Network Mode Direct Mode
- Interface: RS232/RS485
- DVR Protocol: DH2
- Dome Protocol: DH-SD/PELCO-D/PELCO-P/PELCO-D1/PELCO-P1…
- Network Mode Interface: RJ45
- DVR/Network Dome: IP Address/Port/Protocol
- Display LCD, 75.2mm x 33.85mm
- Power Supply Power adapter, input 100V~240V 50Hz / 60Hz, Output DC12V/1000mA
- Power Consumption 5W
- Working Temperature -10° C~+55° C
- Working Humidity 10%~90%
- Atmosphere Pressure 86kpa~106kpa
- Dimension 330mm x 160(140)mm x 37.5(21)mm (W?D?H) (height: 100mm including joystick)
- Weight 2.5KG
