| Specifications |
| Camera |
| Image Sensor |
1/2.5″ Progressive Scan CMOS |
| Min. Illumination |
0.028 Lux @ (F2.0, AGC ON), 0 Lux with IR |
| Shutter Speed |
1/3 s to 1/10,000 s |
| Lens |
4mm, horizontal FOV: 79°, vertical FOV: 42°, diagonal FOV: 95° |
| Lens Mount |
M12 |
| Day & Night |
IR cut filter |
| DNR |
3D DNR |
| Wide Dynamic Range |
True WDR 120dB |
| Angle Adjustment |
Pan:0° ~ 360°, Tilt: 0° ~ 75°, Rotation: 0° ~ 360° |
| Compression Standard |
| Video Compression |
Main stream: H.265/ H.264
Sub stream: H.265/H.264/ MJPEG
Third stream: H.265/ H.264 |
| H.265 Type |
Main Profile |
| Video Bit Rate |
32 Kbps ~ 16 Mbps |
| Dual Stream |
Support |
| Image |
| Max. Resolution |
3840 × 2160 |
| Main Stream |
50Hz: 12.5 fps (3840 × 2160), 20fps (3072 × 1728), 25 fps (2560 × 1440, 1920 × 1080, 1280 × 720)
60Hz: 15 fps (3840 × 2160), 20fps (3072 × 1728), 30 fps (2560 × 1440, 1920 × 1080, 1280 × 720) |
| Sub Stream |
50Hz: 25fps (640 × 480, 640 × 360, 320 × 240)
60Hz: 30fps (640 × 480, 640 × 360, 320 × 240) |
| Third Stream |
50Hz: 25fps (1280×720, 640×360, 352×288)
60Hz: 30fps (1280×720, 640×360, 352×240) |
| Behavior Analysis |
Line crossing detection, intrusion detection |
| Others |
Saturation, Brightness, Contrast adjustable by client software or web browser, Mirror, BLC, ROI, Dual Stream, Anti-Flicker, Privacy Mask |
| Network |
| Network Storage |
Support microSD/SDHC/SDXC card (128GB), local storage and NAS (NFS,SMB/CIFS), ANR |
| Alarm Trigger |
Motion Detection, Tampering Alarm, Intrusion Detection, Line Crossing Detection, HDD Full, HDD Error, Network Disconnected, IP Address Conflicted |
| Protocols |
TCP/IP, UDP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
| General |
Password Protection, IP Address Filtering, Anonymous Access, Watermark |
| Standard |
ONVIF (PROFILE S, PROFILE G), PSIA, CGI, ISAPI |
| Interface |
| Communication Interface |
1 RJ45 10M/100M Self Adaptive Ethernet port |
| Reset |
Yes |
| General |
Working Temperature
/Humidity |
-22 °F ~ 140 °F (-30 °C ~ 60 °C)
Humidity 95% or less (non-condensing) |
| Power Supply |
DC12 V ± 25%, Φ5.5 mm coaxial power plug PoE (802.3af, class 3) |
| Power Consumption |
12 VDC, 0.5A, max. 6W PoE (802.3af, 36V to 57V), 0.3A to 0.2A, max. 7.5W |
| IR Range |
Up to 100ft |
| Weather Proof Ratings |
IP67 |
| Dimensions |
5.01″ × 3.78″ (Φ 127.3 × 95.9 mm) |
| Weight |
1.4 lb. (620 g) |
|
