Mobotix Mx-M16TB-R079 M16B Thermographic Camera TR,50MK
IP thermographic camera TR with Germanium Lens: B079 equivalent, horizontal/vertical image angle 45?/32? ? ONVIF-compliant Mx6 system platform (2nd generation) with H.264, MxPEG+ and M-JPEG ? Thermal radiometry (TR): calibrated thermal sensor for temperature events from -40 to 550?C (-40 to 1022?F) ? NETD typ. 50 mK, <79 mK, IR range 7.5 to 13.5 micrometer, uncooled micro bolometer, up to 9 frames per second, 336 x 252 pixels (can be scaled up to 6MP) ? Optional optical 6MP sensor module (to be ordered individually) ? IP66/IK07, -40 to 60?C (-40 to 140?F) ? Internal DVR: 4 GB microSD ? System components: speaker and microphone (inside housing), PIR sensor, temperature sensor, MxActivitySensor, shock detector ? VarioFlex wall mount (can be used with additional ceiling mount MX-DH-M24-SecureFlex and pole mount MX-MH-SecureFlex-ESWS), ethernet patch cable 0.5 m/1.65 ft ? Interfaces: Ethernet 10/100 (RJ45), MxBus, USB; IO and RS232 via additional MX Interface Box ? Incl. 1 Blind Module (MX-SM-Blind-PW)
The intelligent video system with an integrated high-performance thermal image sensor takes full advantage of the M16B camera design. Thanks to the two directly adjacent lenses, there is also a thermal overlay function with image overlay (thermal and optical) to pinpoint the exact location of hotspots like smoldering fires in a visible image. Thermal radiation measurements made across the entire image area can be used to trigger an event based on the temperature increasing above or decreasing below an individually set trigger level (camera alarm, network message, activation of a signal output etc.).
Features
- Mx6 system platform 2nd generation, with MxBus, H.264 and ONVIF compatibility
- Fixed premium thermal image sensor with an NETD of 50 mK
- Thermal Radiometry For measurable added value: calibrated thermal image sensor
- Thermal field of view: 45?, 25? or 17?
- Recording on an internal MicroSD card (4GB as standard)
- Integrated microphone and speaker
- MxActivitySensor can also be used in total darkness
- PoE thermal camera with a power consumption of < 10 W
