Mobotix MX-M16TB-R119 M16B Thermographic Camera TR, 50 mK, R11

Mobotix MX-M16TB-R119 M16B Thermographic Camera TR, 50 mK, R11

The intelligent video system with an integrated high-performance thermal image sensor takes full advantage of the M16B camera design. Thanks to the two directly adjacent lenses, there is also a thermal overlay function with image overlay (thermal and optical) to pinpoint the exact location of hotspots like smoldering fires in a visible image. Thermal radiation measurements made across the entire image area can be used to trigger an event based on the temperature increasing above or decreasing below an individually set trigger level (camera alarm, network message, activation of a signal output etc.).

The intelligent video system with an integrated high-performance thermal image sensor takes full advantage of the M16B camera design. Thanks to the two directly adjacent lenses, there is also a thermal overlay function with image overlay (thermal and optical) to pinpoint the exact location of hotspots like smoldering fires in a visible image. The MOBOTIX TR cameras feature a calibrated thermal image sensor. Thermal radiation measurements made across the entire image area can be used to trigger an event based on the temperature increasing above or decreasing below an individually set trigger level (camera alarm, network message, activation of a signal output etc.).

IP Thermografic camera with/without Thermal Radiometry technology (TR) and Germanium lens (3 different image angles available); can be optionally equipped with a second optical 6MP sensor module (day/color or night/black and white to be ordered separately for easy self-assembly)

Features

• IP thermographic camera TR with Germanium Lens: B119 equivalent, horizontal/vertical image angle 25?/19?
• ONVIF-compliant
• Mx6 system platform (2nd generation) with H.264, MxPEG+ and M-JPEG
• Thermal radiometry (TR): calibrated thermal sensor for temperature events from -40 to 550?C (-40 to 1022?F)
• NETD typ. 50 mK, 79 mK,
• IR range 7.5 to 13.5 micrometer, uncooled micro bolometer, up to 9 frames per second
• 336 x 252 pixels (can be scaled up to 6MP)
• Integrated microphone and speaker
• MxActivitySensor can also be used in total darkness
• PoE thermal camera with a power consumption of < 10 W
• IP66/IK07, -40 to 60?C (-40 to 140?F)
• Internal DVR: 4 GB microSD
• System components: speaker and microphone (inside housing), PIR sensor, temperature sensor, MxActivitySensor, shock detector VarioFlex wall/ceiling mount (can be used with additional pole mount: MX-MH-SecureFlex-ESWS), ethernet patch cable 0.5 m/1.65ft
• Interfaces: Ethernet 10/100 (RJ45), MxBus, USB; IO and RS232 via additional Interface Box
• Optional optical 6MP sensor module (to be ordered individually)
