User Capacity
Common User
Visitor User
Panic User
|
Hardware User: 1000 APP User: 100 (including 255 fingerprint / card/ PIN users)
988 (100 Fingerprint Users + 888 PIN/Card Users)
10
2
|
| PIN Length |
4~6 digits |
|
Operating Voltage
Idle Current
Active Current
|
12~18V DC
≤ 60mA
≤ 150mA
|
Proximity Card Reader
Radio Technlogy
Read Range |
EM or Mifare
125KHz/13.56MHz
2~6cm |
| Wiring Connections |
Relay output, exit button, alarm, door contact, Wiegand input/output |
|
Relay
Adjustable Relay Output Time
Lock Output Load
|
One (NO, NC, Common)
0~99 Seconds (5 seconds default)
2 Amp Maximum
|
| Wiegand Interface
PIN Output |
EM card version: Wiegand 26~44 bits input & output (Factory default: Wiegand 26bits)
Mifare card version:Wiegand 26~44 bits,56bits,58bits input & output (Factory default: Wiegand 34bits)
4 bits,8bits (ASCII),10 digits Virtual Number(Factory default:4bits) |
|
Environment
Operating Temperature
Operating Humidity
|
Meets IP66
-30°C ~ 60°C (-22°F ~ 140°F)
0%RH ~ 98%RH
|
|
Physical
Color
Dimensions
Unit Weight
Shipping Weight
|
Zinc-Alloy
Sliver & Black
L148 x W43.5 x H22 (mm)
330g
405g
|
