Vertical Cable 060-488/BL Cat6 23AWG UTP 1000ft – Blue

Vertical Cable 060-488/BL Cat6 23AWG UTP 1000ft – Blue

This blue Cat6 cable is conveniently packaged in a box with a built-in dispensing mechanism, making installation and cable management easy and efficient. It is compliant with industry standards, ensuring compatibility with a wide range of network equipment. The cable is suitable for both residential and commercial installations and is designed to meet the demanding requirements of modern networking environments.
Whether you are setting up a home network or a large-scale commercial network, the 060-488/BL Cat6 UTP cable offers reliable performance, fast data speeds, and easy installation, making it an excellent choice for your networking needs.

Specifications

• Wiring Scheme: T568B (most common) or T568A
• Voltage Rating: 300 volts
• Capacitance: 56 pF/m (maximum)
• DC Resistance: 9.38 Ohms/100m (maximum)
• Mutual Capacitance: 5.6 nF/100m (maximum)
• Delay Skew: 45 ns/100m (maximum)
• Return Loss: 20 dB (minimum)
• Attenuation: 23.8 dB/100m at 100 MHz (maximum)
• Crosstalk: Power Sum NEXT (PSNEXT) 44.3 dB/100m at100 MHz (minimum)
• Power Sum ACR (PSACR): 23.3 dB/100m at 100 MHz(minimum)
• Jacket Thickness: 0.5 mm (minimum)
• Cable Diameter: 6.2 mm (approximately)
• These additional specifications further define the performance characteristics of the Cat6 UTP cable. They include parameters related to signal integrity, crosstalk, attenuation, and electrical properties. The cable meets or exceeds these specifications to ensure reliable and high-quality data transmission.

Features

• High Bandwidth: The Cat6 cable is designed to support high-speed data transmission with bandwidth capabilities of up to 250 MHz. This makes it suitable for demanding applications such as Gigabit Ethernet, video streaming, and large file transfers.
• Enhanced Performance: The cable is built with 23AWGsolid copper conductors, which provide superior conductivity and minimize signal loss. This ensures reliable and consistent network performance, even over long cable runs.
• Durable Construction: The cable features a sturdy construction with a high-quality PVC jacket, which provides excellent protection against external interference, abrasion, and environmental factors. It is designed to withstand bending, pulling, and other physical stresses commonly encountered during installation.
• Easy Identification: The blue color of the cable jacket allows for easy identification and differentiation from other cables in the network infrastructure. This simplifies cable management and troubleshooting tasks, especially in complex installations.
• Versatile Compatibility: The Cat6 cable is backward compatible with previous generations of Ethernet standards, such as Cat5 and Cat5e. This means it can be used in existing network setups or upgraded systems without compatibility issues.
• Easy Installation: The cable is supplied in a convenient1000ft box, which provides ample length for various installation scenarios. It is easy to pull, route, and terminate, thanks to its flexible design and clear labeling.
• RoHS Compliant: The cable is compliant with the Restriction of Hazardous Substances (RoHS) directive, which restricts the use of hazardous materials in electronic and electrical equipment. This ensures a safer and more environmentally friendly product.
