Vertical Cable 062-504/S/BL CAT6 550MHZ HDBT STP 8C 1000ft – Blue

Vertical Cable 062-504/S/BL CAT6 550MHZ HDBT STP 8C 1000ft – Blue

The 1000ft (305 meters) length of the cable ensures that you have sufficient length to connect devices across different rooms or locations without the need for additional splicing or extensions. This generous length provides flexibility in installation, allowing you to customize your network setup according to your specific requirements.

The blue color of the cable jacket allows for easy identification and differentiation from other cables in your network infrastructure. This simplifies cable management, troubleshooting, and maintenance, saving time and effort.

The cable is constructed with high-quality materials to ensure durability and long-lasting performance. The PVC (Polyvinyl Chloride) jacket provides protection against physical damage, moisture, and environmental factors, making it suitable for both indoor and outdoor installations.

In terms of wiring configuration, the cable features 8 conductors and follows the TIA/EIA-568-C.2 wiring standard. This standard ensures compatibility and interoperability with other networking devices and equipment.

Specifications

• Cable Type: CAT6 Shielded (STP)
• Cable Length: 1000ft (305 meters)
• Conductor Type: Solid Copper
• Conductor Gauge: 23 AWG
• Shielding Type: Foil and Braided
• Jacket Material: PVC (Polyvinyl Chloride)
• Jacket Color: Blue
• Wiring Standard: TIA/EIA-568-C.2
• Frequency Rating: Up to 550 MHz
• Data Transmission Rate: Up to 10 Gbps
• Connector Type: RJ-45
• Wiring Configuration: 8 conductors, 4 pairs
• Impedance: 100 Ohms
• Shielding Effectiveness: Provides excellent protection against electromagnetic interference (EMI) and crosstalk
• Flame Rating: CMR (Riser rated)
• RoHS Compliant: Yes
• Compliance: Meets ANSI/TIA-568-C.2 standards for enhanced performance and reliability
• Operating Temperature: -20?C to +75?C (-4?F to +167?F)
• Pull-Through Design: Yes, for easier installation and cable management
• Certifications: UL Listed, ETL Verified

Features

• High-Speed Performance: The CAT6 specification of the cable ensures high-speed data transmission, capable of supporting bandwidth-intensive tasks such as streaming multimedia, online gaming, and large file transfers. It provides a reliable and fast network connection for efficient data transfer.
• Enhanced Signal Integrity: The shielded twisted pair (STP) design of the cable offers superior protection against electromagnetic interference (EMI) and crosstalk. This helps to maintain optimal signal integrity and minimize signal degradation, ensuring reliable and consistent data transmission.
• Future-Proof Solution: The CAT6 standard provides higher bandwidth capabilities, making this cable a future-proof solution for your network infrastructure. It allows for potential upgrades and supports emerging technologies, ensuring that your network can adapt to evolving demands.
• Versatile Compatibility: The cable is compatible with a wide range of network devices and equipment, including computers, servers, routers, switches, and more. It provides a universal connectivity solution for various networking applications, making it suitable for both residential and commercial installations.
• Easy Installation and Management: The cable’s solid conductor design and flexibility make it easy to handle and install. It can be routed through walls, conduits, or cable trays with ease, providing flexibility in network design and deployment. The pull-through design further simplifies installation, saving time and effort.
• Durable and Reliable: The PVC jacket of the cable offers durability and protection against physical damage, moisture, and environmental factors. It ensures that the cable withstands the demands of networking installations and provides long-lasting performance.
• Easy Identification: The blue color of the cable jacket allows for easy identification and differentiation from other cables in your network setup. This simplifies cable management, organization, and troubleshooting, making it easier to identify specific connections within your network infrastructure.
• Industry Compliance: The cable meets ANSI/TIA-568-C.2 standards for enhanced performance and reliability. It is also UL Listed and ETL Verified, ensuring that it has undergone rigorous testing and meets the highest industry standards.
